Vericut Icam Interfaces for CAD/CAM Systems, CNC Machines & Controllers

Icam Post interfaces help manufacturers move more seamlessly from CAM programming to machine-ready NC code, simulation, verification and production.

Built to support all major CAD/CAM systems, machine tools, and CNC controllers, Icam Post helps create a more connected manufacturing workflow between the software you program in, and the machines you rely on.

Connect CAM programming  to CNC execution.

Modern CNC manufacturing depends on connected software.

Your CAM system creates the toolpaths. Your post-processor converts them into machine-specific NC code. Your simulation software verifies the output. Your CNC machine executes the program.

Icam Post interfaces help link all those stages together.

By supporting major CAD/CAM systems, machine tools and CNC controllers, Icam Post helps manufacturers reduce manual data transfer, improve NC program quality, support custom post-processor development, and create a more reliable path from programming to production.

Supported CAD/CAM interfaces.

Icam Post has long-standing experience supporting major CAD/CAM systems used by manufacturers worldwide.

These integrations help manufacturers keep working in the CAD/CAM software they already know, while using Icam Post and Vericut technology to support post-processing, simulation, verification, and optimization.

Mastercam

Collaborate seamlessly across devices from wherever you may be – whether you’re in the office, on the go, or making last-minute changes before your next meeting.

I think of this as a design resource that really helps you find the vision on sections and pages that often can seem boring to design. It does a great job of providing you alternative options that you can easily extend.

Siemens NX CAM

Icam Post connects with Siemens NX CAM workflows, helping manufacturers connect NX programming with post-processing, simulation and optimized NC output.

With Icam Post Adaptive Post-Processing technology, manufacturers can post-process, simulate G-code and optimize toolpaths within a more connected workflow.

CATIA and 3DEXPERIENCE

Icam Post works with both CATIA and 3DEXPERIENCE manufacturing workflows.

Icam Post has a contract with CATIA 3DEXPERIENCE, and can drive CAM capabilities within DELMIA. This helps manufacturers using Dassault Systèmes environments connect programming, post-processing, simulation and machine-ready NC output more effectively.

For CATIA V5 users, Icam Post also supports post-processing and simulation workflows designed to help NC programmers create, simulate and optimize NC programs with greater efficiency.

Creo

Icam Post supports Creo programming environments, helping manufacturers connect Creo-based CAM data with custom post processors, machine simulation and optimized NC output.

PowerMill

Icam Post is compatible with PowerMill workflows for manufacturers that need machine-specific NC code, post-processing support and simulation-ready output for complex CNC machining.

hyperMILL

Icam Post enables hyperMILL workflows for manufacturers programming complex components, including multi-axis machining applications that require accurate post-processing and machine-specific output.

CAMWorks

Icam Post interface technology can help CAMWorks environments by connecting CAM programming data with post-processing, simulation, and CNC machine output.

Image Card (2)

Image Card (3)

FeatureCAM

Icam Post can support FeatureCAM-based workflows where manufacturers need custom post-processing and machine-specific NC program generation.

Fusion 360

Icam Post can assist Autodesk Fusion 360 manufacturing workflows that require post-processing, machine-specific NC code, and a connected path to simulation and verification.

Custom post-processors for any CAD/CAM software.

Icam Post is widely recognized for custom CNC post-processor development.

Rather than forcing manufacturers into a single programming environment, Icam Post is designed to support multiple major CAD/CAM systems.

This helps manufacturers create post-processors that integrate with the software, machines, controllers, and production processes they already use.

Media (83)

A custom CNC post-processor can help translate CAM output into machine-ready NC code while accounting for:

Machine kinematics.
Controller syntax.
Rotary axis behavior.
Machine limits.
Canned cycles.
Tool changes.

Macros.
Probing routines.
Coordinate transformations.
Multi-axis motion.
Mill-turn operations.
Shop-floor programming standards.

This makes Icam Post interface technology valuable for manufacturers using a single CAM system, multiple CAM systems, or different programming environments across different facilities.

MODIG

As a Preferred Machine Tool Partner, MODIG has chosen Icam Post for all its factory-approved post-processors and simulators. This close integration means that MODIG users can get all of the benefits of Icam Post’s software suite built into their CNC equipment from the manufacturer.

Image Card (4)

bavius

As a Preferred Machine Tool Partner, bavius technologie has been one of the world’s leading manufacturers of 5-axis high-performance machining centers for more than 30 years. They offer standardized machine concepts with a modular design to be flexible in finding the optimum solution for your machining requirements.

Image Card (5)

Mazak

Through the collaborative initiatives of Vericut Icam and Mazak, customers can rest assured they have access to Mazak’s state-of-the-art machining capabilities via their CAD/CAM/PLM system and Vericut Icam’s advanced NC post-processing products.

Image Card (6)

DMG MORI

The sharing of technical knowledge and other resources enables the successful integration of Icam Post and DMG MORI's respective products and services, ultimately enabling end-users to benefit from advanced DMG machine tool features via their CAD/CAM/PLM systems.

Image Card (7)

DMG MORI

By combining OMAX’s Intelli-MAX control software with advanced NC post-processors from Icam Post, OMAX, & MAXIEM owners stand to benefit from the sophisticated features found in high-end 3D CAD/CAM packages.

Media (84)

Makino

Icam Post offers a custom advanced post-processing development solution geared to deliver optimized results for all Makino machines. Icam Post’s custom NC post-processors are created using advanced kinematics models and offer support for up to 15 axes of control.

Image Card (8)

Starrag

Starrag customers can benefit from Icam Post’s extensive NC post-processing experience with advanced multi-axis machining applications and techniques, including high-speed machining, tool-tip programming, coordinate frame transformations, NURBS interpolation, and arc fitting of point-to-point data.

Image Card (9)

G-code simulation and control emulation.

Icam Post supports G-code simulation and control-emulation workflows to help manufacturers verify the code that will be sent to the machine.

This is important because the CAM toolpath is not always identical to the final NC program. The post-processor, controller logic, machine functions, macros, and manual edits can all affect what the machine will actually do.

Media (85)

Media (86)

G-code simulation helps manufacturers:

Verify post-processed NC code.
Simulate controller-specific output.
Check machine behavior before production.
Detect possible collisions or motion issues.
Reduce prove-out time.
Improve confidence in machine-ready code.
Identify problems introduced after CAM programming.

CAD/CAM system

Creates toolpaths and manufacturing programming data.

Icam Post interface

Connects CAM data to post-processing and machine-specific output.

CAM-POST®

Generates CNC machine-ready NC code.

G-code simulation and machine verification

Checks post-processed output before production.

Vericut

Simulates, verifies, and optimizes for total manufacturing confidence.

CNC machine

Runs verified, machine-ready NC code.

Machine simulation during  post-processing.

SmartPATH® and SmartCUT™ can be especially powerful when used together.

SmartCUT™ detects air-cut segments and identifies where the tool is not engaged with material. Instead of simply increasing speed along the same programmed path, SmartPATH® can calculate a faster, safer path to the start of the next cut.

Together, they help manufacturers improve NC programs by combining air-cut elimination with intelligent path optimization.

Media (63)

Work with the software you  already use

Connect major CAD/CAM systems with Icam and Vericut workflows without rebuilding your programming process from scratch.

Reduce manual data transfer

Move more manufacturing information through a connected workflow, reducing duplicated effort and manual setup.

Improve post-processor accuracy

Develop machine-specific and controller-specific post-processors using the data and behavior required by your manufacturing environment.

Support complex CNC machines

Create output for 5-axis machines, mill-turn centers, multi-tasking machines, and special-purpose CNC equipment.

Verify real machine code

Use G-code simulation and machine verification to check the code that will actually run on the CNC machine.

Improve programming consistency

Support consistent NC output across multiple CAM systems, machines, controllers, and production teams.

Reduce prove-out risk

Identify issues digitally before programs reach the shop floor.

Need to connect  your CAD/CAM system, machine  or controller?

Talk to Vericut about your programming environment, CNC machines, controllers, and interface requirements. Our team can help you understand how Icam and Vericut interface technology can support your workflow, from CAD/CAM programming to post-processing, G-code simulation, machine verification, and production-ready NC output.

Media (87)
